Specification |
SFC-21-5CV |
SFC-21-7CV |
| GENERAL |
General Type |
Heavy-duty industrial/commercial |
Heavy-duty industrial/commercial |
|
Brand |
Kohler® Command PRO® |
Kohler® Command PRO® |
|
Model |
CV173 |
CV224 |
|
Horsepower |
5HP @ 3300 RPM |
7HP @ 3300 RPM |
|
Type |
4 cycle gas, OHV, air-cooled, single-cylinder, vertical shaft engine |
4 cycle gas, OHV, air-cooled, single-cylinder, vertical shaft engine |
|
Displacement |
173 cc |
224 cc |
|
Cylinder |
One with cast-iron cylinder bore |
One with cast-iron cylinder bore |
|
Governor |
Mechanical governor with variable speed control set at 3300 rpm, idle set at 1500 rpm |
Mechanical governor with variable speed control set at 3300 rpm, idle set at 1500 rpm |
|
Air Cleaner |
Quad-Clean™ four-stage, cyclonic air filter |
Quad-Clean™ four-stage, cyclonic air filter |
|
Exhaust |
Side discharge muffler with guard |
Front discharge muffler with guard |
|
Oil Pump Group |
Steel oil pump; Full pressure lubrication with spin-on oil filter |
Steel oil pump; Full pressure lubrication with spin-on oil filter |
|
Starter/Electrical |
Easy-Pull™ recoil start |
Easy-Pull™ recoil start |
|
50-State Compliant |
Yes |
|
| ENGINE DECK |
Thickness |
14 gauge |
14 gauge |
|
Fuel Tank |
0.37 gallon (1.4 liters) plastic tank |
1 gallon (3.785 liters) plastic tank |
|
Wheels/Tires |
Drive: 10.5 x 3 / Front: 9 x 2.25 |
Drive: 10.5 x 3 / Front: 9 x 2.25 |
|
Handle Bars |
1″ diameter, thick wall tubing, 3-position adjustable |
1″ diameter, thick wall tubing, 3-position adjustable |
| DRIVE SYSTEM |
Type |
Transmission |
Transmission |
|
Transmission |
GT MG 512 transmission, 3-speed |
GT MG 512 transmission, 3-speed |
|
Steering/Travel Control |
Variable drive control bar and 3-speed selector lever on handlebar |
Variable drive control bar and 3-speed selector lever on handlebar |
|
Transmission Output Shaft |
0.50″ diameter |
0.50″ diameter |
|
Safety Group |
Handle actuated operator presence system |
Handle actuated operator presence system |
|
Forward Speed |
Up to 4.25 mph |
Up to 4.25 mph |
| CUTTER DECK |
Type |
High-vacuum, high-capacity design |
High-vacuum, high-capacity design |
|
Construction |
14 gauge deck with 14-gauge replaceable guards for strength and longevity. Deep draw stamped. |
14 gauge deck with 14-gauge replaceable guards for strength and longevity. Deep draw stamped. |
|
True Cutting Width |
21 inches (53.34 cm) |
21 inches (53.34 cm) |
|
Cutting Height Adjustment |
1.5″ to 4.5″ in 0.5″ increments |
1.5″ to 4.5″ in 0.5″ increments |
|
Cutter Blade |
0.1345 in. thick, milled edge, wear resistant |
0.1345 in. thick, milled edge, wear resistant |
|
Blade Engagement |
Blade control bar controlled Blade Brake Clutch (BBC). Connected to cutter blade. |
Blade control bar controlled Blade Brake Clutch (BBC). Connected to cutter blade. |
|
Discharge Opening |
Rear-discharge. Extra wide discharge opening. /td> |
Rear-discharge. Extra wide discharge opening. |
|
Clutch Type |
Heavy-duty Blade Brake Clutch (BBC) |
Heavy-duty Blade Brake Clutch (BBC) |
| OPTIONAL ITEMS/ATTACHMENTS |
Mulching Plug |
Included |
Included |
|
Fabric Grass Catcher |
Included; 2.2 bushels (2.74 cu. ft.) |
Included; 2.2 bushels (2.74 cu. ft.) |
|
Side-Discharge Adapter |
Available accessory |
Available access |
